Microscope Objective HC FLUOTAR L 16x/0,80 IMM motCORR VISIR
Obj. HC FLUOTAR L 16x/0,80 IMM motCORR VISIR
Product No. 11507706
Objective HC FLUOTAR L 16x/0,80 IMM motCORR VISIR has a magnification of 16X and a numerical aperture of 0.8. For use in immersive immersion material environment and attached with an objective thread of M32 having a free working distance of 8.15mm and a FN of 20.
| Light | Transmitted Light (TL) |
| Contrasting Methods | Brightfield, Fluorescence |
| Technique/Application | Confocal Microscopy, Electrophysiology, MP (Multi Photon) |
| Numerical Aperture | 0.8 |
| Objective Type | HC FLUOTAR L VISIR |
| Immersion | IMM |
| Coverglass | With and without Coverglass |
| Objective Thread | M32 |
| Free Working Distance (WD in mm) | 8.15 |
| Field Number (FN) | 20 |
| Magnification | 16 |
| Iris Diaphragm | NO |
| Spring Loaded | NO |
| Suitable for AFC (Adaptive Focus Control) | NO |
| Correction Ring (CORR) | motCORR |
| Exit Pupil Position/DIC prism | NO |
| Numeric Aperture Filter | 0.65 - 0.95 |
| Magnification Filter | 16x |
| Field Number Filter | 20 - 24 |
| Working Distance Filter | Long WD |
