Microscope Objective HC FLUOTAR L 16x/0,60 IMM CORR VISIR
$undefined
Obj.HC FLUOTAR L 16x/0.60 IMM CORR VISIR
Product No. 11506533
Objective HC FLUOTAR L 16x/0,60 IMM CORR VISIR has a magnification of 16X and a numerical aperture of 0.6. For use in immersive incl BABB immersion material environment and attached with an objective thread of M25 having a free working distance of 2.50mm and a FN of 20.
| Light | Transmitted Light (TL) |
| Contrasting Methods | Brightfield, Differential Interference Contrast, Fluorescence |
| Technique/Application | Confocal Microscopy, MP (Multi Photon) |
| Transmission | IR (up to 1300nm) |
| Numerical Aperture | 0.6 |
| Objective Type | HC FLUOTAR L VISIR |
| Immersion | IMM incl BABB |
| Coverglass | With and without Coverglass |
| Objective Thread | M25 |
| Free Working Distance (WD in mm) | 2.50 |
| Field Number (FN) | 20 |
| Magnification | 16 |
| Iris Diaphragm | NO |
| Spring Loaded | NO |
| Suitable for AFC (Adaptive Focus Control) | YES |
| Correction Ring (CORR) | CORR |
| Exit Pupil Position/DIC prism | D |
| Numeric Aperture Filter | 0.35 - 0.6 |
| Magnification Filter | 16x |
| Field Number Filter | 20 - 24 |
| Working Distance Filter | Long WD |
