Next Generation STELLARIS Confocal Microscope

Next Generation STELLARIS Confocal Platform

STELLARIS is a true confocal point scanning system, including a White Light Laser as excitation light source, an Acousto Optical Beam Splitter (AOBS) and a highly sensitive, prism-based spectral detection design with computer controlled adjustable bandwidth for all fluorescence channels. The extended detection range up to 850 nm plus the excitation range in the visible from 440 nm up to 790 nm (different models available on request) allow the application and separation of an extended range of spectrally overlapping fluorophores.

Including TauSense, a set of tools based on fluorescence lifetime information, it provides an additional contrast, improved image quality and separation of spectrally overlapping fluorophores. LIGHTNING allows for optimal extraction of image details and maximum resolution, thus expanding the imaging portfolio both in the classical range and beyond the diffraction limit.

STELLARIS can feature a tandem scanning system to provide highest axial resolution with galvanometric scanner, switchable between resonant and non-resonant mode.

STELLARIS can be equipped with Power HyD S detector, new standard for detection. The Power HyD S is an all-round detector with high performance throughout the spectrum and two times increased photon detection efficiency in the blue-green range compared to standard multialkaline photomultiplier. Power Hybrid Detector HyD X and HyD R are specialists for FALCON (FAst Lifetime CONtrast) , FCS and TauSTED Xtend in the visible up to near infrared detection.

Configuration will be tailored to your specific needs – Request a quote

Power to see more: Imagine the power to observe finer details in every sample, capture the faintest signals, gather more precise data across the spectrum and push your spatial discoveries with high multiplexing. Productivity to do more: Consider the enhanced productivity that comes with simplified setup and navigation, allowing you to acquire images from complex samples with just a few clicks and focus on data that matters with Autonomous Microscopy Powered by Aivia

Power HyD S SP Core Unit Pos 3

158301313

QTY

SP Light Trap

158201310

QTY

Control panel with LCDs

158004752

QTY

Power HyD S SP pos 2

158301312

QTY

Power HyD S SP pos 4

158301314

QTY

STELLARIS WLL

158401100

QTY

STELLARIS Power cable Zone 2

158209011

QTY

FOV Scanner STELLARIS

158301130

QTY

Fluorifier Disc Basis inkl. Analysator

158204510

QTY

Scan optics HIVISR w.rotation Dmi8/DM8

158301120

QTY

STELLARIS DMi8 adapter

158401140

QTY

Notch filter set VIS base

158204511

QTY

Cable Scanning Stage, 3 m, 90°

15500332

QTY

Microscope Objective HC PL APO 40x/1.30 Oil CS2

15506428

QTY

Microscope Objective HC PL APO 20x/0.75 CS2

15506517

QTY

Type F Immersion liquid, ISO 8036

15513859

QTY

IC Condenser Prism K7

15521522

QTY

XY advanced board for scanning stage

15525226

QTY

Smart Move I²C

15525232

QTY

Filter Cube GFP

15525314

QTY

IC Prism C

15555009

QTY

IC Condenser Prism K3

15555017

QTY

IC Prism E

15555046

QTY

Aivia Go 1 year

27100022

QTY

Bino Tube

155933660

QTY

Transmission axis

155933666

QTY

DMi8 CS Premium

155933668

QTY

Base Plate DMi8

158000640

QTY

Optical Table 750 x 900 actively damped

158002407

QTY

High brilliance monitor

158003150

QTY

Scanning stage inv. universal

158004141

QTY

BF detector for DMI.

158004201

QTY

SuperZ Galvo Stage

158004421

QTY

Insert Rotatable Inverse SuperZ

158004423

QTY

pE 300 white MB

158200681

QTY

Laser 405 DMOD

158202140

QTY

Workstation Silver

158203114

QTY

LAS X STELLARIS Control Software

158203200

QTY

DSE powered by Aivia

158203220

QTY

Closed Loop Focus

158204201

QTY

Fluorifier Disc Basis inkl. Analysator

158204510

QTY

Computer table

158204709

QTY

Laser Port 405

158301200

QTY

Service Installation

9I_LL_STELLARIS_C

QTY

Confocal Training Class C

9T-CLSM-APP_CLASSC

QTY

Warranty Extension STELLARIS 405

9WE_LAS_405

QTY

Warranty Extension STELLARIS WLL

9WE_LAS_WLL

QTY

Warranty Extension

9WE_LL_STELLARIS_C

QTY
