MZ10F for Fluorescence Sorting
The MZ10-F stereo microscope is a cutting-edge instrument designed for precision and clarity in microscopic observation. With its advanced optics and ergonomic design, this microscope is particularly well-suited for cell sorting applications. Delivering exceptional image quality and versatility, the MZ10-F enhances the efficiency and accuracy of cell sorting processes, making it an indispensable tool for researchers and professionals in the field of life sciences.
- Magnification range: 8x-80x (1.0x objective, 10x eyepieces)
- Click stop zoom settings
- Triple Beam TM: Separate illumination beam path for fluorescence
- Four position fluorescence filter turret
- Objective thread M65
Features
- 10:1 zoom range with high numerical aperture of 0.125 for excellent representation of small structures
- TripleBeam™, Leica’s patented separate beam path for extremely intense fluorescence illumination
- FLUOIII™, Leica’s patented, 4-position, rapid change filter system
- Wide range of standard filters and availability of custom filters for almost any fluorescence technique
- Comprehensive user protection against UV radiation
- Innovative contrast possibilities with Leica’s high-performance transmitted light bases
| Microscope Camera Option(s) | Optional |
| Microscopy Software Available | 3D Visualization, Multichannel Acquisition |
| Has Eyepiece | Yes |
| Microscope Type(s) | Stereo Microscope, Macroscope |
| Has Resonance Scanner | No |
| Microscope Environmental Control | None |
| Maximum Field of View (X-Axis) (Metric mm) | 28.8 mm |
| Maximum Field of View (Y-Axis) (Metric mm) | 28.8 mm |
| Maximum Optical Magnification (x times) | 80 |
Leica MZ10 F optics carrier
10450103
1
QTY
Eyepiece 10x/23B, adj., eyeglasses
10447137
2
QTY
Focus drive coarse/fine 420mm M-series
10450504
1
QTY
Microscope carrier for MZ-Series
10450104
1
QTY
Dust cover (40 x 35 x 75 cm), antistatic
10450287
1
QTY
TL3000 Ergo
10450690
1
QTY
ST Adapter column on TL Bases
10450242
1
QTY
Microscope Objective HC PL APO 1.0x M-series
10450028
1
QTY
Filter set ET GFP - MZ10F
10450588
1
QTY
Leica LED5000 SLI
10450548
1
QTY
Clamp-combi light guide - highend M-ser
10450205
1
QTY
Coupling for fluid light guide, EL6000
10447399
1
QTY
pE 300 white MB
11504264
1
QTY
Inclined binocular tube 45° M-Series
10450252
1
QTY
Fluid light guide Ø3x2000mm / series 380
11504269
1
QTY
Service Installation
9I_SM_CLASS_D
1
QTY
Power cable, 2 m, EURO
10445662
3
QTY
