Ivesta 3 for Routine Sorting

The Ivesta 3 stereo microscope is an ideal solution for routine sorting applications. Engineered with precision optics and user-friendly features, this microscope offers exceptional clarity and ease of use. With its advanced capabilities, the Ivesta 3 streamlines routine sorting processes, providing researchers and professionals with a reliable and efficient tool for daily laboratory tasks. Elevate your workflow with the performance and convenience offered by the Ivesta 3 stereo microscope.

Limited time promotion - get a free LED3000 RL Ring Light with your purchase.

Specifications:

9:1 zoom with magnification 6.1x-55x (10x eyepieces, no supplementary lens) – provides field of view up to 37.6mm for fast, accurate inspection
12 mm Depth of Field with Fusion Optics. Greenough optical design - provides very flat (plan) field of view and large depth of field
Complete apochromatic corrected microscopy system - 35° angle eye tubes - for comfort and convenience
122 mm standard working distance (without lens shield) – ensures excellent accessibility to the samples
Resolution up to 250 lp/mm (without supplementary lens, 10x eyepieces), maximum resolution up to 500 lp/mm (2x supplementary lens, 10x eyepieces)
Antimicrobial PC/ABS housing with AgTreat™
Clickstops at 10x 20x 30x 40x and 50x – inspection at specific magnification can be easily repeated
Large range of supplementary lenses as well as eyepieces

For observation only, when no camera is required for documentation Conveniently handle samples with a large working distance of up to 122 mm Reveal fine details with a magnification of up to 55x and apochromatically corrected optics Enersight software interface can be used in multiple operation modes, such as on-screen display, mobile devices, or computer

Instrumentation
Contrasting Method(s)	Brightfield
Long Working Distance	Yes
Microscope Stage Type(s)	Manual
Microscope Camera Option(s)	No Camera
Has Eyepiece	Yes
Microscope Type(s)	Light Microscope, Stereo Microscope
Microscope Environmental Control	None
Maximum Field of View (X-Axis) (Metric mm)	37.6 mm
Maximum Field of View (Y-Axis) (Metric mm)	37.6 mm
Maximum Optical Magnification (x times)	55

Search Facet
Microscope Group	Light Microscope
Application(s)	Automotive and Transportation;Electronics and Semiconductor;Inspection

Ivesta 3

10450983

QTY

Eyepiece 10x/23B, adj., eyeglasses

10447137

QTY

Focus column for S-Line

10446339

QTY

Incident light base, small

10446340

QTY

Sub base with reflector

10446341

QTY

KL300 LED Bracket for routine focusdrive

31120212

QTY

Universal light guide, 600 mm

10446392

QTY

Dust cover antistatic, small

10447039

QTY

KL300 LED fiberoptic light source w/ps

31120300

QTY
