A60 F Inspection and Rework Microscope with Flexarm Stand
The A60 F stereo microscope with a flexible Flexarm stand is an exceptional tool for inspection and rework applications. Engineered for precision and versatility, this microscope provides unparalleled clarity and flexibility in various workspaces. The innovative Flexarm stand allows users to position the microscope effortlessly for detailed inspection and intricate rework tasks. With its superior optics and adjustable design, the A60 F is the perfect solution for professionals seeking a reliable and adaptable stereo microscope to enhance the efficiency and accuracy of their inspection and rework processes.
- 6:1 zoom ratio
- Zoom range: 5x-30x
- 122 mm working distance,
- Ergonomic 38° viewing angle
- Max. 46 mm field of view
- Unique depth of field (zoom optics is based on the concept of the patent of FusionOptics®)
- Patented, anti-static plastic covers: ZeroStat with exchangeable protection glass
- 2x 10x/23 high eye point eyepieces with adjustable diopters and eyecups
- LED ring light with designed focus lens for homogeneous and bright illumination, approx. 50 000 operating hours, approx. 5600K colour temperature
- Diffusor to reduce reflections (removable)
- Universal power supply, 100V-240V
- Inclinable focus arm with 50 mm travel range, incl. flex arm stand
- The table clamp allows maximum freedom of movement while requiring minimum table space
- Easy viewing of the sample in x and y directions
- Easy height adjustment for different sample heights
- Maximum space savings provided by table clamp fastening
Features
| Contrasting Method(s) | Brightfield |
| Long Working Distance | Yes |
| Microscope Stage Type(s) | Manual |
| Microscope Camera Option(s) | No Camera |
| Has Eyepiece | Yes |
| Microscope Type(s) | Stereo Microscope |
| Has Resonance Scanner | No |
| Microscope Environmental Control | None |
| Maximum Field of View (X-Axis) (Metric mm) | 46 mm |
| Maximum Field of View (Y-Axis) (Metric mm) | 46 mm |
| Maximum Optical Magnification (x times) | 30 |
Leica A60 F
10450311
1
QTY
Polarisation set for LED3000 RL
10450337
1
QTY
Power cable, 2 m, EURO
10445662
1
QTY
